Javier Gómez Laina                                                                          ngc6543 - Cat's eye nebula

(click on the image for full resolution)



About the object:      (texto en español)
The Cat's Eye Nebula (NGC 6543) is a planetary nebula in the constellation of Draco. Structurally, it is one of the most complex nebulae known.  It was discovered by William Herschel on 1786.    Modern studies reveal several mysteries;  the intricacy of the structure may be caused in part by material ejected from a binary central star, but as yet, there is no direct evidence that the central star has a companion.   The concentric rings surrounding the inner nebula seem to have been ejected at intervals of a few hundred years, a timescale which is rather difficult to explain.    While the bright inner nebula is rather small at 20 arcseconds in diameter, it has an extended halo of matter that the progenitor star ejected during its red giant phase. This halo extends over a diameter of about 6.4 arcminutes.   . (From Wikipedia)


About the image:
This image is my longest total exposure:  more than 36 hours!  It's the only way to get the beautiful but very faint nebula's envelopment, whereas its core is so bright that difraction spikes blur the image instead of the more usual knife-sharp effect seen on brilliant stars.





Object:             ngc 6543 - planetary nebula
Telescope:
COMELLAS  telescope  (250 f/8.3 Newton). Lumicon 1.8x  multiplier/corrector.
Camera:           Artemis ART4021.   IDAS, Baader & Astronomik filters.
Exposures:       Oiii:                  46 x 1800"   ( 23:00 )
                         Ha:                   16 x 1800"   (  8:00 )
                         L (LPS filter):    31 x 600"     (  5:10 total)
                         L, Oiii, Ha, R, G, B:  several 30" & 120" exposures for core detail

Resolution:       0.73"/pixel
Guiding:            MX716 on Off-Axis Guider
Date:                 10 - 30 Jul  2008
Site:                  Sagan Observatory  Las Rozas  (Spain)     - mag 4.5 suburban skies -
Processing:
Bias, Darks & Flat calibration
SDMask combining
Curves and wavelets adjust
LRGB:  L (LPS-Oiii-Ha);   R (Ha);  G (Oiii);   B (Oiii)


Software:
MaximDL, PixInSight



El objeto:

La nebulosa del Ojo del Gato (ngc 6543) es una nebulosa planetaria en la constelación de Draco.  Estructuralmente, es una de las más complejas nebulosas conocidas.  Fue descubierta por William Herschel en 1786.   Estudios modernos revelan varios misterios; la estructura intricada puede estar causada por una estrella central binaria pero, hasta ahora, no hay evidencia que la estrella tenga una compañera.    Los anillos concéntricos que rodean la nebulosa interior parecen haber sido expelidos a intervalos de unos pocos cientos de años, una escala de tiempo que es bastante difícil de explicar.   Mientras la brillante zona interior es bastante pequeña, con un diámetro de 20 arcosegundos, está rodeada por un extenso halo de materia expulsada por la estrella progenitora durante su fase de gigante roja. Este halo se extiende alrededor de 6.4 minutos de arco.  (Fuente: Wikipedia)

 La imagen:
Esta imagen es la que tiene mi mayor tiempo total de exposición: ¡más de 36 horas!  Es la única forma de conseguir la preciosa pero muy débil envoltura exterior de la nebulosa, mientras que su núcleo es tan brillante que sus líneas de difracción emborronan la imagen, en vez de tener el efecto de afilado contraste visto en las estrellas brillantes.
